Getting a crop planted at the correct time, at the correct depth, and in the correct environment are the fundamental keys in setting a stage for maximum yield potential. These are the key fundamentals that Maestro row crop planter technology are based on. Technology and design that maximize every minute of the optimum planting window to secure maximum potential yield. A complete design concept to ensure precise placement of each seed to achieve rapid germination and uniform emergence. This is a platform that protects soil structure integrity during planting. The Maestro row crop planter is the only planter on the market today with a common-sense approach in design that incorporates basic agronomic principals for securing maximum yield potentials. We use three terms to describe this unit – simple, robust, precise.
Please fill out the form below and you will be redirected to your download.
Series | Model | Configuration | Row Configuration | Seed Tank Size | Fertilizer Tank Size | Transport Height | Transport Width Singles (Duals) [Tracks] |
---|---|---|---|---|---|---|---|
3800 | 1230 | Seed Only | 30 in | 110 bu | N/A | 12' | 12' |
3800 | 1230 | Liquid | 30 in | 110 bu | 400 gal | 12' | 12' |
3800 | 1630 | Seed Only | 30 in | 110 bu | N/A | 12' 9" | 12' |
3800 | 1630 | Liquid | 30 in | 110 bu | 600 gal | 12' 9" | 12' |
5800 | 1630 | Seed Only | 30 in | 166 bu | N/A | 12' 9" | 12' 6" (17' 6") |
5800 | 1630 | Liquid | 30 in | 83 bu | 725 gal | 12' 9" | 12' 6" (17' 6") |
5800 | 2420 | Seed Only | 30 in | 166 bu | N/A | 12' 9" | 12' 6" (15' 1") |
5800 | 2420 | Liquid | 30 in | 83 bu | 725 gal | 12' 9" | 12' 6" (15' 1") |
5800 | 2422 | Seed Only | 22 in | 166 bu | N/A | 13' 5" | (16' 3") [14' 10"] |
5800 | 2422 | Liquid | 22 in | 83 bu | 730 gal | 13' 5" | (16' 3") [14' 10"] |
5800 | 3115 | Seed Only | 30 in/15 in | 166 bu | N/A | 13' 5" | (12' 6") [17' 6"] |
5800 | 3215 | Seed Only | 30 in/15 in | 166 bu | N/A | 13' 5" | (12' 6") [17' 6"] |
8800 | 1630 | Dry | 30 in | 83 bu | 2 - 83 bu | 13' 8" | 12' 6" (17' 6") |
8800 | 2420 | Liquid | 20 in | 166 bu | 730 gal | 13' 5" | (15' 3") [13' 10"] |
8800 | 2420 | Dry | 20 in | 83 bu | 2 - 83 bu | 13' 8" | 13' 5" |
8800 | 2422 | Dry | 22 in | 83 bu | 2 - 83 bu | 13' 8" | 13' 5" |
8800 | 2430 | Seed Only | 30 in | 249 bu | N/A | 13' 6" | 12' 6" (17' 6") |
8800 | 2430 | Liquid | 30 in | 166 bu | 730 gal | 13' 6" | 12' 6" (17' 6") |
8800 | 2430 | Dry | 30 in | 83 bu | 2 - 83 bu | 13' 8" | (17' 6") |
8800 | 3115 | Liquid | 30 in/15 in | 166 bu | 730 gal | 13' 5" | 12' 6" (17' 6") |
8800 | 3215 | Liquid | 30 in/15 in | 166 bu | 730 gal | 13' 5" | (12' 6") [17' 6"] |
8800 | 3620 | Seed Only | 20 in | 249 bu | N/A | 13' 1" | (15' 3") |
8800 | 3620 | Liquid | 20 in | 166 bu | 730 gal | 13' 1" | (15' 3") |
8800 | 3622 | Seed Only | 22 in | 249 bu | N/A | 13' 2" | (16') |
8800 | 3622 | Liquid | 22 in | 166 bu | 730 gal | 13' 2" | (16') |
8800 | 4715 | Seed Only | 15 in | 249 bu | N/A | 14' 2" | (17' 5") [14' 7"] |
8800 | 4715 | Liquid | 15 in | 166 bu | 730 gal | 14' 2" | (17' 5") [14' 7"] |
8800 | 4815 | Seed Only | 15 in | 249 bu | N/A | 14' 2" | (17' 5") [14' 7"] |
8800 | 4815 | Liquid | 15 in | 166 bu | 730 gal | 14' 2" | (17' 5") [14' 7"] |
